DSHB132 Diesel Oil Cetane Number Tester
Product Description
DSHB132 Diesel Oil Cetane Number Tester
A:Introduction
DSHB132 is a new generation detector for cetane measurement, with international advanced theory, it can measure the oil’s cetane precise value rapidly, store large amount of data; and all the results are printable. The interface is user-friendly. Its sensors adopt full-sealed design with alloying metal. With longer standby-cyclic charging battery, it applies in operation site, outdoor and lab.
B:Main Features
1. DSHB132 can measure diesel’s cetane value.
2. Rapid and precise measurement, user-friendly operation, larger screen with /English language, EL background light make it’s easier under dark environment, English menu is also available;
3. Tree years quality guarantee for circuit board: we promise for free replacement within three years for any non-artificial quality problems. The sensors adopt full-sealed design with alloying metal. External cover has high strength, shock resistance and water/dust/moisture proof performance. As well as sponge inside.
4. Upper and lower limits pre-setting are available, the monitor will display when it’s over the limit, which is convenient for the users.
5. Auto-off function can save energy and realize low power consumption. There are 4 reliable batteries for recycling charging.
C:Measurement Theory
The theory of cetane detector is based on the measurement of insulate-magnetic permeability and feature of electro-magnetic induction. By detecting the dielectric medium of oil and comparing with the data model, the detector can measure out the value of cetane. The precise sensors can measure out parameters fluctuation of the tiny mediums, then get the result of cetane.
Technical Data Sheet
Technical Parameters
| NO. | Parameters Description | Value |
| 1 | Measurement item | All kinds of diesel |
| 2 | Measurement of diesel’s cetane reach standards | ASTM D4737-03, ASTM D613, EN ISO 5165 |
| 3 | range of measurement | Cetane number:20-100(accuracy±1) |
| 4 | the measuring time of each sample | <20seconds |
| 5 | consuming current | 30mA |
| 6 | Battery operating time | 100 hours |
| 7 | Operation condition | Temperature of -10°C~+40°C, relative humidity of 30%~81% R.H., barometric pressure of 64~106kPa. |
